FARFISA intercom systems

Farfisa Smart Access App (on Alba or Hero door stations to be integrated with XE2922 board), which allows the access control via Bluetooth though smartphone (for authorized users)

Farfisa Smart Dial App (on Alba or Hero door stations to be integrated with XE2922 board), which allows – via Bluetooth – to make the call without touching the surface of the panel, because it replaces the door station with your smartphone (as a visitor)

HERO, the innovative door panel offers the top in terms of technological performance and security, using top-level materials and finishes, offering excellent solutions for big complex and in particular regarding accessibility to the world of disabled people.

To the touch, the sensation is robustness and elegance together, cold and smooth, modern and reliable. Hero will capture you.

The line consists of a single element: a large panel made of 316L stainless steel, with large steel keys and 6 Tamper Resistant Torx screws, for flush mounting. All these characteristics help guarantee the vandal-proof by combining the best ergonomics and maximum technological performance. Hero is designed for Duo video systems with bus power supply, Hero manages the extended range Duo system, therefore it can be used as the main external unit on systems with up to 20,000 users and with maximum distances between external and internal units. Ideal for large complexes, it has a digital keyboard consisting of 14 large keys, backlit also in the outline of the button, very large and backlit graphic display, wide angle camera, status icons and various pluses that make Hero a top level of accessibility to the world of disabled people. Hero manages up to 500 users with individual passwords, it is ready for mechanical assembly of any proximity readers. 2 independent outputs: 1 for electric lock and 1 with relay for automatic gate or other lock.

From the point of view of accessibility, Hero embraces the strictest guidelines and aligns itself with internationally recognized regulations, declaring itself compliant with the DDA “Disability Discrimination Act”.

If integrated with the XE2922 board, Hero can be connected with the apps Farfisa Smart Access and Farfisa Smart Dial for contactless access control, through smartphone via Bluetooth, thus contributing to the containment of covid-19 (notouch / nocovid) contagion

Among other features we highlight: → voice prompt for audio indication of the call or system status (in various languages, deactivated by programming) → raised, large, backlit keys in Braille also evident in the outline, more visible also for the visually impaired → large, backlit graphic display, such as status icons, for optimal reading even in unfavorable lighting conditions → wide angle camera as standard, for greater security and for allow a correct view of any category of visitor → series integration of inductive loop for coupling with devices hearing aids for the hearing impaired

Programming can be done via Bluetooth, with the Duo app for iOS and Android or through integrated digital keyboard.

Agorà is the elegant and robust video door station, with slim and compact shape. Surface mounted -therefore extremely easy to install- this modular range is characterized by the very thin profile, so it slightly protrudes from the wall. Even in width, the module has reduced dimension, colour camera is conceived with pin-hole lens while front plate is made in anodised extruded aluminium. Name-holders are back lit in original blue colour for easy identification even in poor lighting conditions.

Agorà can be used with all Farfisa internal stations for Farfisa IP Way system, Duo System, 2-wire digital technology and analogue reduced wiring technology.

Characterised by state-of-the-art design, ECHOS is the most innovative ACI FARFISA videointercom line. The aesthetically pleasant structure, perfectly harmonised with new trends of interior architecture, delivers the most sought-after operational features. Echos has been developed in colour version, with 3.5” LCD that can be adjusted on the horizontal axis to compensate for reflections and ensure correct vision for the user.

Moreover, it has been conceived in hands-free mode: once you have made the connection by simply pressing the activation button, your hands will be free with no traditional handset. It’s provided with intuitive function-buttons for door lock release, self-switch on of display, ring tone deactivation (with LED for status indication), audio volume and picture brightness adjustment, intercommunication, if available, and some additional features. The system takes advantage of the electronic call note to ensure the best sound quality. Echos has been designed for the most demanded technologies, starting from the digital system Duo System or FN4000, including reduced or conventional wiring installations.

Modern and elegant, Matrix Style is the modular range for solid and antivandal door station, with high level finishes and materials. The series is conceived to be resistant to breaking, water spout and solid penetration. These technical specifications are granted by IP45 for solid items introduction protection and IK09 degree for mechanical shocks. Front frames are available even in matt titanium grey colour, while the plates are mirror-polished, that combine elegance and long-standing life. All the modules are backlit thanks to green LED’s for easy identification especially in poorly illuminated situations. The modularity allows installations of great number of users and configurations in vertical or horizontal way. The range is complete with aluminium front frames and built-in or surface mounting boxes. In a single module can be integrated push button, door speaker and camera, so that Matrix Style can be the ideal solution starting from one-way installations up to the most complex cases. Matrix Style is available for digital Duo System, FN4000 and DF6000 systems or for analogue technologies with reduced or conventional wiring. Matrix Style is the strength of antivandal with the best Italian style

Farfisa is proud of Alba; it represents a goal, its name means Sunrise in Italian, a shining and appropriate name for a new entrepreneurial spirit and new industrial visions.

Totally Made in Italy, Alba stands out for its high-level design conceived for the best Farfisa technologies. Modularity and flexibility, concealed structural elements, luminous icons and attention to accessibility make Alba the line of entry door stations that gives you the composition you need with maximum ease of installation, the top of usability even in maintenance and updating.

The series consists of standalone elements that coexist in compositions: audio/video- or only audio button module (elegant and compact, allows up to 4 calls with a single module), module for digital keypad or access control or expansion for MyCom system, display module or proximity reader module. Accessories and various additional elements complete the range.

Alba stands out for its sensitivity and attention to the disabled: the wide angle of the camera pushed to allow people in wheelchairs to be framed, it can be equipped with a specific coil to facilitate compatibility with hearing aids for hearing impaired users, printing on the button of call is in relief in Braille, for the recognition by the blind, the flashing signal of forwarded call helps the hearing impaired users.

The front plate is made of anodised aluminum with brushed finish, color camera with a 2.3 mm focal length and wide-angle lens, camera-integrated loudspeaker and microphone in the lower part not visible, particularly protected internal mechanics and electronics, therefore weatherproof, IP55. The 3 LEDs light up the icons to indicate the status: call sending, busy, active conversation, door lock release. Alba has 2 independent outputs for lock activating and other loads, assembly is simplified and speed and the push-button panel on Duo System is self-powered with automatic address learning. Alba manages the “Duo extended” range system, so it can be used as the main external unit of the systems for up to 20000 users and with very long distance between external and internal units. With built-in or surface mounting, Alba is also suitable for renovations thanks to compatibility with Farfisa series and others.

Alba can be programmed and managed through Bluetooth technology for an higher confort, speed, reliability and usability for the installer and for the end-user too.

If integrated with the XE2922 board, Alba can be connected with the apps Farfisa Smart Access and Farfisa Smart Dial for contactless access control, through smartphone via Bluetooth, thus contributing to the containment of covid-19 (notouch / nocovid) contagion

Characterised by modern lines and great reliability, Profilo is a modular series of external door stations for intercom or videointercom installations, including with high complexity level. The front plates are made of anodised extruded aluminium with steel call buttons. The name plates are backlit with green light for better visibility in poor lighting conditions. The strength of the line is the excellent optimisation of the module size, which makes Profilo especially suitable for systems with small rooms, such as installation in gates.

The range also includes video or audio elements with double call button with integrated electrical door speaker. In combination with push-button modules, back boxes and relevant accessories, a high number of users can be achieved. Profilo is available in all Aci Farfisa technologies, from Duo System and FN4000 digital system up to reduced or conventional wiring with coaxil cable.

Farfisa is proud to introduce its new range of indoor stations, Sette. The design is extremely rigorous: slim, carefully balanced lines define an ultra-flat monitor conveying a gracefully elegant and light impression, thanks to the attractive sharp profile with 45° edges, coupled with a distinct character enhanced by the step separating the display from the controls area.

The range is named ‘Sette’ and ‘Italian View’ is its payoff, because it shows the broadest possible view for maximum security. The screen is 7” and is of guaranteed quality thanks to the customary 100% Italian design and manufacturing. LED-lit icons, soft-touch buttons and controls on the graphic interface allow for managing the advanced video door entry functions, for digital 2 wire technologies available: Duo System and Pluggy, respectively with art. SE4252 and SE7PG (dedicated to 1SEPG videokits).
